• Imaging sensor: 1/1.8" Progressive Scan CMOS
• Maximum Resolution: 3840 × 2160
• Minimum Exposure:
  • Colour: 0.0008 Lux @ (F1.0, AGC ON)
  • Black/White: 0 Lux with IR
• Shutter speed: 1/3 s to 1/100,000 s
• Day & Night: IR filter
• Angle adjustment:
  • Pan: 0° to 360°
  • Tilt: 0° to 90°
  • Rotation: 0° to 360°

Lens

• Lens Type: Fixed focal length lens, 2.8 mm and 4 mm optional
• Focal Length & Field of View:
  • 2.8 mm: Horizontal FOV 105.1°, Vertical FOV 54.8°, Diagonal FOV 128.2°
  • 4 mm: Horizontal FOV 90.0°, Vertical FOV 45.8°, Diagonal FOV 109.4°
• Lensbevestiging: M16
• Aperture Type: Fixed
• Diafragma: F1.0
• Depth of Field:
  • 2.8 mm: 3.3 m to ∞
  • 4 mm: 3.8 m to ∞

DORI

• 2.8 mm:
  • Detection: 89 m
  • Observation: 35 m
  • Recognition: 17 m
  • Identification: 8 m
• 4 mm:
  • Detection: 109 m
  • Observation: 43 m
  • Recognition: 21 m
  • Identification: 10 m

Verlichting

• Supplementary Illumination Type: IR
• Range of Supplementary Illumination:
  • 2I: up to 60 m
  • 4I: up to 80 m
• Smart Supplementary Lighting: yes
• IR Wavelength: 850 nm

Video

• Hoofdstroom:
  • 50 Hz: 25 fps (3840 × 2160, 3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
  • 60 Hz: 24 fps (3840 × 2160), 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
• Substream:
  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
• Third Stream:
  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
  • 60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
• Video Compression:
  • Hoofdstroom: H.265/H.264/H.264+/H.265+
  • Substream: H.265/H.264/MJPEG
  • Third stream: H.265/H.264
• Video Bitrate: 32 Kbps to 16 Mbps
• H.264 Type: Baseline Profile, Main Profile, High Profile
• H.265 Type: Main Profile
• Bitrate Control: CBR, VBR
• Scalable Video Codecs (SVC): H.264 and H.265 encoding
• Region of Interest (ROI): 1 fixed region for main stream and substream

Netwerk

• Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, SRTP, SFTP
• Simultaneous Live View: up to 6 channels
• API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
• User/Host: Up to 32 users
• Security: Password protection, HTTPS encryption, 802.1X authentication, watermark, IP address filter, TLS 1.1/1.2/1.3, host authentication (MAC address)
• Network storage: NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
• Client: iVMS-4200, Hik-Connect, Hik-Central
• Web browser: Plug-in requires live view: IE 10, IE 11; Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+

Beeld

• Picture settings: Rotation mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable via client software or web browser
• Day/Night Switch: Day, Night, Automatic, Schedule
• Picture Enhancement: BLC, HLC, 3D DNR
• SNR: ≥ 52 dB
• Wide Dynamic Range (WDR): 120 dB
• Privacy Masking: 4 programmable polygon privacy masks

Interface

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage: Integrated memory card slot, supports microSD/microSDHC/microSDXC card, up to 512 GB
• Resetknop: Ja

Algemeen

• Current: 12 VDC ± 25%, 0.95 A, max 11.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3, max 12.5 W
• Material: Front cover: metal, housing: metal, bracket: metal
• Dimensions: 286.7 mm × 93.3 mm × 91.2 mm (11.3" × 3.7" × 3.6")
• Weight: Approximately 1180 g (2.6 lb.)
• Storage conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• Start-up and Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F), Humidity 95% or less (non-condensing)
• General Features: Heart rate, mirror, password reset via e-mail, pixel counter, anti-banding
